    Programmable Logic Controller Mitsubishi PLC Module Q61SP

    Ask Lasest Price
    Brand Name : Mistubishi
    Model Number : Q61SP, Q61P Mitsubishi
    Supply Ability : 10pc/per week
    Price : $50-$500
    Payment Terms : T/T, western union
    Delivery Time : within 3 working days
    MOQ : 1 Set
    • Product Details
    • Company Profile

    Programmable Logic Controller Mitsubishi PLC Module Q61SP

    Programmable Logic Controller Mitsubishi PLC Module Q61SP

    MELSEC-Q series slim type power supply unit.
    Features
    ・ It supplies power to various units such as CPU unit and input/output unit (It must be mounted on a slim type base)
    ・ External Dimensions: (H) 98 mm, (W) 27.4 mm, (D) 104 mm
    ・ Weight: 0.18 kg
    Applications
    ・ Power supply to the unit


    Base mounting positionSlim type power supply unit mounting slot
    Compatible base unitQ3 □ SB
    Input power supply voltageAC100-240V (-15% -+ 10%)
    Input frequency50 / 60Hz ± 5%
    Input voltage distortionWithin 5%
    Input maximum apparent power40VA
    Inrush current40A within 8ms
    Rated output currentDC5V2A
    Overcurrent protectionDC5V2.2A or higher
    Overvoltage protectionDC5V5.5-6.5V
    efficiencyover 70
    Allowable momentary power failure timeWithin 20ms
    Withstand voltageBetween input / LG batch and output / FG batch AC2300V / 1min (elevation 0-2000m)
    Insulation resistanceInput / LG batch and output / FG batch, input batch and LG, output batch and FG: DC500V insulation resistance tester 10MΩ or more
    Operation displayLED display (normal: green, abnormal: off)
    fuseBuilt-in (user exchange not possible)
    External wiring connection methodScrew terminal block (M3.5 screw)
    External dimensionsHeight (H)98mm
    Width (W)27.4mm
    Depth (D)104mm
    mass0.18kg
